Slide 1

Cells and Organelles;

Cells and Organelles;

The Cell Membrane

Book Reference: p.16-p.19

Slide 2

Do all membranes have the same basic structure?

Do all membranes have the same basic structure?

Both the cell surface membrane and the membranes surrounding certain organelles have the same basic structure. Much of the membrane is made up of a 'sea' of phospholipids with protein molecules 'floating' in between the phospholipids.

Slide 3

Where are proteins located within the membrane?

Where are proteins located within the membrane?

What is an intrinsic protein?

What is an extrinsic protein?

Why is it called the fluid mosaic model?

Slide 4

INTRINSIC 1:

INTRINSIC 1:

Channel Proteins

Allow movement of substances, such as glucose, across the membrane

NO ATP REQUIRED

Slide 5

Actively transport substances, such as minerals, across the membrane

Actively transport substances, such as minerals, across the membrane

ATP is REQUIRED

INTRINSIC 2:

Carrier Proteins

Slide 6

(a) Channel VS (b) Carrier

(a) Channel VS (b) Carrier

Proteins

Slide 7

Bilayer; Phospholipids

Bilayer; Phospholipids

What is the bilayer?

The phosphate heads are polar molecules and so are water-soluble.

The lipid tails are non-polar and therefore are not water-soluble.

Slide 8

Why do phospholipids have both a hydrophilic and a hydrophobic part?

Why do phospholipids have both a hydrophilic and a hydrophobic part?

The phosphate heads are polar. Are they water-soluble?

The lipid tails are non-polar. Are they water-soluble?

Slide 9

What is a polysaccharide?

What is a polysaccharide?

Clue: polymer; monomer; carbohydrate

Slide 10

Bilayer; Phospholipids

Slide 11

Glyco……what?

Glyco……what?

What is the difference between a glycoprotein and a glycolipid?

Slide 12

What is the role of glycoproteins?

What is the role of glycoproteins?

They may help in the recognition of, and interaction with, other cells. They may also play a part in the recognition of hormones and foreign molecules.

Slide 13

What is the role of cholesterol in the cell membrane?

What is the role of cholesterol in the cell membrane?

Cholesterol is also present in the membrane. It maintains the fluidity and increases the stability of the membrane. Without cholesterol the membrane would easily split apart
